ENGINE TYPE
V-Twin, liquid cooled, 4-stroke, SOHC, 8-valve
DISPLACEMENT
963cc
MAX POWER
84 HP @ 7500 RPM
MAX TORQUE
62 LB-FT @ 5500 RPM
FUEL SYSTEM
EFI
COOLING SYSTEM
Liquid cooled
DRIVE
2WD/4WD/4WD lock
TRANSMISSION
OmniDrive™ CVT P/R/N/H/L
STARTER
Electric
DIMENSIONS & WEIGHT
LENGTH X WIDTH X HEIGHT
92” x 50” x 57.7”
WHEELBASE
58”
DRY WEIGHT
975 lbs.
GROUND CLEARANCE
12”
FUEL TANK CAPACITY
6.9 gal.
RACK CAPACITY
Front/Rear: 99 lbs./198 lbs.
SEAT HEIGHT
22"
TURNING RADIUS
10.9'
CHASSIS
SUSPENSION
Front: High clearance A-arm, independent / Rear: Trailing arm independent
WHEELS
Front/Rear: 14” Cast aluminum alloy
TIRES
Front: 27" x 9" x R14 / Rear: 27" x 11" x R14
SHOCKS
Front/Rear: High pressure gas w/ piggyback reservoir, compression and rebound adjustable
BRAKING
Front/Rear: Hydraulic disc with parking brake
WHEEL TRAVEL
Front/Rear: 9" / 9"
